Flame Resistant SM Fiber Optic Patch Cord G.652D LC-ST Simplex and Duplex

Flame Resistant SM Fiber Optic Patch Cord G.652D LC-ST Simplex and Duplex

Product Details:

Place of Origin: China
Brand Name: FOCABLE
Certification: RoHS Compliant, SGS Certificate, ISO Certificate
Model Number: SM Duplex Fiber Patch Cord SC/APC- LC/APC

Payment & Shipping Terms:

Minimum Order Quantity: 10PCS
Packaging Details: 1PCS/PE Bag
Delivery Time: 3-5days
Get Best Price Contact Now

Detail Information

Fiber Type: SM Cable Material: LSZH
Cable Diameter: 3.0mm Connector: SC/APC, LC/APC
Cores: Duplex Length: 5M
High Light:

simplex fiber patch cord

,

multimode fiber optic cable

Product Description

Flame Resistant SM Fiber Optic Patch Cord G.652D LC-ST Simplex and Duplex

We FOC COMMUNICATION CO., LTD provide all types of fiber optic patch cords including single mode, multimode, simplex, duplex, multi core patch cords, armored patch cords and waterproof patch cords. The main connectors are FC, SC, LC, ST, MU, MTRJ, E2000, MPO, MTP and so on.



G.652D SM duplex indoor type SC-ST patch cable with OFNP cable is used to connect the device to another for signal routing. It is composed of a fiber optic cable assembled with various connectors on both ends.



Key Features
1. SC-ST Connectors
2. Single mode simplex and duplex fiber optic cable
3. Micron: 9/125um
4. High precision ceramic fiber optic ferrule
5. 100% optically tested to ensure high performance
6. Cable color yellow



Specifications

Item

Specifications

IL(insertion loss)

<0.3dB

RL(return loss)

PC≥50dB, APC≥60dB

Interchangeability

≤0.2dB

Repeatability

≤0.1dB(1000times)

Vibration

≤0.1dB(550Hz, 1.5mm)

Operating Temperature

-40~80℃



Ordering information

1.Connector one, LC,FC,SC,ST,MTRJ,DIN,D4,E2000,MPO, Connector two LC,FC,SC,ST,MTRJ,DIN,D4,E2000,MPO.
2.Ferrule interface type: UPC,APC
3.Fiber type; singlemode(G652,G655),MULTIMODE(50/125, 62.5/125),OM3
4.Fiber cable diameter(mm):Φ0.9, Φ2.0 ,Φ3.0
5.Cable length: Customized length
